Product Features
| Product Code | LDS22 | ||||||
Electrical Data |
|||||||
| Input Voltage Range | AC 100-300 V | ||||||
| Power factor | ≥0.95 | ||||||
| Power Consumption | 22 w±5% | ||||||
Photometric Data |
|||||||
| Rated Luminous Flux | 2420 Lm | ||||||
| LED Light Source | SMD | ||||||
| Color Rendering Index (CRI) | ≥80 | ||||||
| Beam Angle | 120° | ||||||
| Luminous Efficiency | 90-100Lm/W | ||||||
| Color Temperature (CCT) | 3000K (WW), 4000K (NWH), 6000K (WH) | ||||||
| Working Temperature | 0°c to + 50°c | ||||||
Luminaire Data |
|||||||
| Dimension | L:220mm, W:220mm, H:36mm | ||||||
| Ceiling Cutout | L:205mm, W:205mm | ||||||
| Rated Life | 40000 Hours | ||||||
| IP Rating | IP40 | ||||||
| Luminaire Body & Finish | ABS plastic with PC Diffuser | ||||||
